Neurophysiological characteristics in argininemia: a case report

Introduction

Argininemia (arginase deficiency or hyperargininemia; OMIM 207800) is an autosomal recessive inherited disease caused by the deficiency of arginase 1, which is a rare type of urea cycle disorder (UCD) (1). The gradual loss of mental and motor abilities, increasing severity of spasticity, and symptoms of pyramidal tracts are hallmarks of the disease. The pathophysiology of pyramidal tract dysfunction remains to be clarified. Brain magnetic resonance imaging (MRI) shows a variable degree of cerebral and cerebellum atrophy, while no metabolic abnormality was observed in a magnetic resonance spectroscopy study (2). Neurophysiological assessments such as motor evoked potentials (MEPs), somatosensory evoked potentials (SEPs), nerve conduction velocity (NCV), and F-wave provide a non-invasive objective method to evaluate both the central and peripheral nervous system, which is valuable in infants and young children (3,4).

To our knowledge, neurophysiological evaluation in patients with argininemia has rarely been reported. Liver transplantation (LT) has been suggested to prevent progressive neurological impairment in argininemia (5). It is lucky for us to manage an argininemia patient who needed LT to improve the symptoms. Herein, we reported the neurologic, neurophysiological, clinical, and neuroimaging findings of argininemia to elucidate the pathophysiology and evaluate the effect of LT.

We present the following case in accordance with the CARE reporting checklist (available at https://dx.doi.org/10.21037/tp-21-112).

Case presentation

A 13-year-old male patient was admitted to our hospital. Spastic paraplegia, weakness of bilateral lower limbs, and tip-toeing gait were observed on admission. Protein aversion appeared at the age of 5 years old without any other symptoms. The patient developed dragging of the right lower limb four years ago, which was progressive to spastic paraplegia of both lower limbs recently. The patient showed significant social dysfunction, emotional instability, irritability, poor appetite, slow speech with discontinuity. His height was 175 cm. It was difficult for him to bend down and stand up independently. Neurological examination revealed pyramidal tract signs in bilateral lower limbs, spastic gait abnormality, hyperreflexia of knee and ankle reflex, hypermyotonia, positive ankle clonus and Babinski signs, strength decreased to grade IV, while the upper limbs were unaffected. His spasticity severity score was 38/54 as assessed by the Spastic Paraplegia Rating Scale (SPRS) (6). Complex hereditary spastic paraplegias (HSPs) were diagnosed at first. The diagnosis of argininemia was confirmed by plasma amino acids analysis and gene sequencing. Blood arginine concentration was 150.9 μmol/L (reference range, 5–25 μmol/L) on the first examination and reached a maximum of 289.1 μmol/L. The likely pathogenic mutation, c.647T>C (p.L216P) and pathogenic mutation, c.263-266delAGAA (p.k88Rfs*45), were identified in the ARG1 gene from his genomic DNA. His younger sister showed without any symptoms. Laboratory examination showed mild coagulation disorder without bleeding symptoms. Brain MRI revealed mild cerebral atrophy (Figure 1). The patient responded poorly to dietary management consisting of protein restriction, sodium benzoate, and sodium phenylbutyrate therapy. He could not walk or stand independently before surgery, just one month after admission.

Figure 1 Mild cerebellar atrophy is observed in the sagittal T2-weighted image.

Neurophysiological evaluation

Assessment of long fiber tracts included MEPs of the upper and lower limb corticospinal tracts and SEPs of lower limb afferent somatosensory tracts. NCV and F-wave evaluated the peripheral nervous system. Motor NCV was recorded at the tibial nerve, common peroneal nerve, median nerve, ulnar nerve, and sensory NCV at the superficial peroneal nerve, median nerve, sural nerve, and ulnar nerve. F-wave was recorded at the tibial nerve. Electromyography (EMG) signals were recorded at the surface of the tibialis anterior muscle, gastrocnemius muscle, and quadriceps femoris muscle. Only tibial SEPs were recorded, and recordings in response to stimulation of the posterior tibial muscle were obtained from the contralateral cortex Cz (2 cm posterior to the Cz), referred to as Fz. The components P40, N50, P60, and N75, were evaluated. MEPs were performed by stimulating the motor cortex with repetitive transcranial magnetic stimulation and recorded at the abductor digiti minimi muscle for the upper limbs and at the tibialis anterior muscle for the lower limbs during relaxation. The central motor conduction time (CMCT) at the target muscle was estimated by subtracting the conduction time from the spinal roots to the muscle and referred to as the peripheral motor conduction time (PMCT) from the latency of MEPs. The center of the magnetic coil was placed over the C7 cervical spine or L4 lumbar spine to stimulate the lower segment's spinal nerve roots to acquire the PMCT. CMCT values of lower limbs were considered abnormal if >20 ms or with a side-to-side difference >2 ms (3). The other indicators were considered abnormal if > mean ± 2.5SD. The reference ranges were obtained from literature data and studies performed at our hospital on healthy age-matched pediatric subjects.

All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Consent for publication was obtained from the guardian of the participant. This study was approved by the Ethics Committee of Beijing Friendship Hospital, Capital Medical University (2020-P2-094-01).

Results

For the scarcity of deceased organs, living-donor LT (LDLT) was performed after the comprehensive pre-operative evaluation. His father was heterozygote as the donor, and the operation was approved by the Ethics Committee of Beijing Friendship Hospital, Capital Medical University. We followed the patient after operation every one or two weeks within three months, then every one month within six months. Although the plasma arginine gradually decreased to an average value six months after the operation, he regained language expression and speech fluency without any social dysfunction within one month. He manifested an excellent appetite and gained 2.5 kg until now. The symptoms of irritability disappeared one-week post-transplant. The knee-jerk reflex returned to normal. The muscle tension of the lower extremity improved significantly at rest, and he could bend down easily; however, gastrocnemii showed hypermyotonia when activity, and the ankles clonus without any improvement. The spasticity severity score decreased to 19/54. Although not all symptoms were improved, he can walk independently for 300 meters without rest or any assists. No complications of the operation affected him.

The data on neurophysiological assessments were obtained two months before the operation. Interestingly, the values of motor and sensory NCV were within normal, and the occurrence rates and latency of F-wave showed no abnormalities. EMG signals indicated that the muscles of the lower limbs were not affected. The latency of SEPs was within normal ranges in bilateral lower limbs. However, prolonged latency of MEPs was observed in bilateral upper and lower limbs, while the PMCT was normal. The CMCT of the lower limbs was 28.3 and 26.7 ms on the left and right side, respectively. The data were listed in Table 1. Until now, we did not perform the second neurophysiological evaluation after the operation.

Table 1 The PMCT, latency of MEPs, and CMCT of bilateral limbs pre-operation
Full table

Discussion

The spastic severity score evaluated by SPRS decreased significantly six months after the surgery. Although the symptoms were not entirely reversed within a short time after the operation, significant improvement suggested that LDLT could prevent aggravation of symptoms (5,7,8).

In addition to protein aversion and language impairment, spastic paraplegia was the primary symptom, which was consistent with previous reports (1,9). The neurophysiological evaluation suggested that the corticospinal tract was primarily damaged. A reduction in diffusion tensor imaging fiber count was observed in a patient with argininemia (10), which indicates that subcortical white matter below the motor cortex may display significant alterations and explain the presence of brain atrophy (2).

Spastic paraplegia of the lower limbs, cerebellar signs, and intellectual developmental disability highlight the importance of argininemia being listed as HSPs (11). Compared with the ascending sensory tract, this patient's neurophysiological data confirmed that descending motor tracts were mainly involved in argininemia. In contrast, the peripheral nerves and muscles were not involved. These findings of this patient are consistent with the research on Hyperornithinemia-hyperammonemia-homocitrullinuria (HHH) syndrome (3). Clinical, neurophysiological, and neuroradiological findings revealed similarities between argininemia, HHH syndrome, and delta-1-pyrrolin-5-carboxylate synthase (P5CS) deficiency. The results indicating a common mechanism related to the impairment of the corticospinal tract is involved in these diseases. In the urea metabolism cycle, arginase deficiency leads to decreased ornithine concentration in the mitochondrial pool, which is a common feature in argininemia, HHH syndrome, and P5CS deficiency (12), and it may be responsible for the common phenotypes. According to a recent study (10), dysmyelination caused by oligodendrocyte injury is the pathological characteristic of argininemia, CMCT and MEP latency are specifically associated with the maturation of the corticospinal tracts (10). Abnormal mitochondrial enlargement and decreased production of adenosine triphosphate (ATP) due to arginase gene mutations have been observed in model of argininemia (13). Taken together, mitochondrial ornithine deficiency may be responsible for oligodendrocyte degeneration and corticospinal tract immaturity in these diseases. And further research should investigate the theory. SEPs have been shown to be valuable for prognosis after brain injury in previous reports (14,15), as sensory input and integration are important in learning motor skills, suggesting that our patient may have a good prognosis.

Of course, heterogeneity of neurophysiological data could exist in argininemia. However, the findings in this patient provide clues for further elucidation of the mechanism of argininemia. In the future, the neurophysiological assessment will likely be applied in argininemia patients frequently.

Conclusions

Our finding highlights the involvement of the corticospinal tract in argininemia; meanwhile, sensory tracts and peripheral nerves are not involved. The results of this patient suggest that argininemia should be listed in complex HSPs. LDLT is an effective strategy for preventing neurological impairment progression in argininemia.
